Fibaro Compact Z-Wave RGBW Controller
Product details
Controller only ~ power supply, LED strip and all other accessories sold separately
Description
The Fibaro RGBW controller is a universal, Z-Wave compatible module that controls single-color, RGB or RGBW LED strips. The device allows you to change the color of the lights from your mobile device whenever you want using the wireless Z-Wave protocol. In addition, the controller also offers four input channels which can be used for push button control or as 0-10V analog sensors inputs for devices such as temperature sensors, humidity sensors, wind sensors, air quality sensors and light sensors. All IN and OUT terminals may be user-configured.
The RGBW controller is small enough to be mounted inside a standard wall switch box. With micro-processor controlled LED dimming, this module also includes power metering features for accurate power measurement and energy saving.
General specifications
- Model: FGRGBWM-441
- Supply voltage: 12-24V DC
- Output: Max. 6A per channel or 12A total
- PWM frequency: 244Hz
- Power metering: Yes
- Command: Z-Wave (universal)
- Inputs: 4x Push button or toggle switch, 0-10V signal, potentiometer
- Wireless range: up to 50m outdoors / up to 30m indoors
- Operational temperature: 32-104°F (0-40°C)
- Dimensions: 42 x 37 x 17 mm (1.65" x 1.46" x 0.67")
