LED Drivers

What’s the best LED driver for your project?

Whether a 12-volt LED dimmable transformer or a 24-volt LED transformer, there are a few things to consider when choosing the best LED driver on the market for your lighting solutions.

First, what type of LED are you using? Each strip uses a different wattage or voltage. It's important to match the voltage of your LED strip to the voltage of the LED driver and also make sure the driver can handle the entire strip load. This will help ensure that your LED strip operates at peak efficiency.

Next, verify if the input of your strip is 12V, 24V, or 48V DC. Check the product specs or markings on the strip. Incorrect voltage input can cause malfunctions and other safety hazards. Do not connect a 12V LED strip to a 24V dimmable LED driver.

Last, you need to decide what type of LED driver you need. We have two main types of LED drivers: Magnitude drivers (24V Dimmable Led Driver M200L24DC - Dimmable Class 2 Electronic LED Driver E96R24DC)  and our Indoor / Outdoor Meanwell LED drivers.

If you do not plan to dim the lights from a wall switch and want to dim them with one of our dimmers, you will need a compatible non-dimmable Meanwell LED driver. Why? The driver will not be used to dim the lights. The dimmer that is installed after the driver will do all the work.

If you plan on using a wall switch to dim your LED lights, then you will need a Magnitude LED driver. The wall switch dimmer will control the magnetic dimmable LED driver.

Basic overview of our ranges of LED driver for sale:

• Magnitude - LED dimmer transformer.
• VLM - Non-dimmable super slim LED driver that can fit into small spaces like our LED channels.
• HLG - Indoor/Outdoor Drivers.
• XLG - LED Driver.
• Casambi LED driver - Bluetooth LED Drivers.

Magnitude LED magnetic driver

Why are they a great option for your LED fixtures?

A good design is achievable only with high-quality lighting products, and hence quality products are the solution to a good functioning lighting setup. If you're looking for the best materials for your commercial, Industrial, or residential projects, a Magnitude lighting LED driver needs to be on your radar.

Magnitude Lighting is one of the first companies in the industry to bring 12 and 24-volt LED drivers into the lighting market.

Reasons to consider getting Magnitude dimmable LED power supply:

• 5-year warranty on all 12V and 24V constant voltage dimmable LED drivers.
• UL Listed.
• Weatherproof NEMA 3R enclosure for 12 and 24-volt LED driver.
• Compatible with 12 and 24-volt dimmable LED drivers.
• Auto-Reset breakers protect both the driver and the LED load.


Models we carry( but we have access to the entire range):

Magnitude Magnetic Electronic LED drivers

12 volt dimmable led driver

• E40R12DC

24vdc dimmable led driver

• E40L24DC-KO
• E60L24DC-KO
• E96L24DC-KO - The Magnitude Lighting E96L24DC-KO falls into Class 2 as it is below 100watts. Full specs here: 24-volt dimmable transformer.

Magnitude LED magnetic transformers.

12 volt led dimmable transformer

• M150L12DC
• M300L12DC


24v dimmable led driver

• M96L24DC-AR
• M150L24DC
• M200L24DC - The Dimmable Magnetic Core 200W 24V LED driver is perfect for commercial applications; it comes with a NEMA 3R high-quality coated metal box. You can find it here: 200 watt LED driver.
• M300L24DC - Our biggest dimmable LED power supply 24V - 12V M series. A great option for large projects.

VLM small-led driver

This range of non-dimmable, mini-led drivers is stocked in 12v led driver and 24v led driver versions. The ERP vlm100w 24 is the biggest of the range, being a 100 watt 24 volts-led driver, and the smallest is the vlm40w 24

LED driver 12v dc versions

• vlm40w-12
• vlm60w-12
• vlm100w 12

24 volt led transformer versions

• vlm40w 24
• vlm60w 24
• vlm100w 24

The ERP driver is the smallest, high-quality 100w led driver on the market and can be used as a led strip light driver inside LED channels and fixtures.

Meanwell LED driver

These excellent led drivers are ideal indoor or outdoor led drivers. The Meanwell LED driver part numbers can be misleading, so always take note of the wattage stipulated on the spec sheet. For example:- the HLG-240h-12V only has an output of 192watts at 12v as compared to the HLG-240h-24 IS A 240watt 24v driver.

Meanwell HLG vs XLG

The XLG Series is a new generation LED waterproof driver that compares to the HLG series. XLG series comes in as an economical version with a compact size, high efficiency energy saving (up to 90%) AC/DC LED drivers. XLG family covers overs from 25W to 240W, with the innovative design improving surge protection level (Line-Earth: 6KV and Line-Line: 4KV), allowing for more reliable installations, which is especially crucial for outdoor applications. XLG series applies the constant power design; it can be used for LED Strip, Bay lights, Streetlight or Horticulture lighting,landscape lighting and flood light applications. The XLG is a constant power driver, and HLG is available as constant voltage/constant current or constant current. XLG also has a 5-year warranty vs HLG series - has a 7-year warranty.

Models we carry( but we have access to the entire range):

Meanwell HLG Series

• Meanwell HLG 40h 12a
• Meanwell HLG 40h 24a
• Meanwell HLG 80h 12a
• Meanwell HLG 80h 24a
• Meanwell HLG 120h 12a
• Meanwell HLG 120h 24a
• Meanwell HLG 150h 12a
• Meanwell HLG 150h 24a
• Meanwell HLG 240 12a
• Meanwell HLG 240h 24a
• Meanwell HLG 320h 12a
• Meanwell HLG 320h 24a

XLG Meanwell Series

• Meanwell XLG 75 24
• Meanwell XLG 200 24

Casambi Bluetooth Wireless LED Driver

The Casambi lighting system works beautifully for under cabinet-led lighting wireless installations and in fact, most wireless-led strip lighting applications.

The Casambi app is an Easy wireless app that is available for Android and IOS devices. The led driver makes your wireless led strip installation simple with the ability to add a arrange of remotes and sensors to compliment your setup.

Models available

LED-808631:- This is a 160w 24 volt dimmable led driver

FAQ

Q: What is an LED Driver used for?

A: An LED driver is a device that regulates and supplies the current used to "drive" an LED strip light. Like a conventional transformer, it converts the mains AC voltage (120 VAC) to lower voltages (12V, 24V, 48V).

Q: Is the Magnitude driver suitable for commercial installations?

A: Our 12 and 24V LED dimmable drivers are perfect for multiple applications, whether residential or commercial lighting fixtures.

Q: Can a driver handle more than one run of LED lights?

A: Yes, whether you get a 12-volt dimmable transformer or a 24-volt one, make sure the driver you are using can handle the total wattage of all the LED strip runs.

Q: How do I know what size power supply I need?

A: Take the length of your LED strip in meters and multiply it by the watts consumed per meter, then multiply by 1.2.

Let’s look at an example: If you want to install 5 meters of LED lights and you know that the strip consumes 8.4W/m, multiply 5 meters by 8.4W/m = 42W. Then multiply the total by 1.2 = 50W. This means that you will need a LED driver that is rated for at least 50W. Remember, this prevents your power supply from overheating and failing prematurely.

Q: Are LED drivers interchangeable?

A: Whether your project requires a dimmable led driver or a non-dimmable driver, you have to keep in mind that LED drivers are not standardized, so they are not interchangeable. They can vary in terms of output characteristics, electrical safety rating, input voltage, programmability, temperature rating, and dimming interface.

Q: What is a 120V to 24V LED driver?

A: A 24V dimmable LED transformer allows you to convert the standard 120V to 24V DC so that you can power LED strips under low voltage.

Q: Is my LED power supply IP65 outdoor-rated?

A: IP65 Rating means the product has the highest level of dust protection and is able to withstand low-pressure water jets from all directions.

We carry 12V and 24V dimmable drivers that are suitable for residential or commercial projects. Make sure to check the product description or your LED driver label to see if it's compatible with your project.

Q: Is the 24 volt dimmable transformer the same as a 24 Volt led driver?

A: yes, generally, people use the same word, driver or transformer, interchangeably

Q: Can I use a 24 volt LED power supply on a 12V LED?

A: No. Using a 24 volt LED power supply with a 12V LED is not recommended and could potentially damage the LED. LEDs are designed to operate within a specific voltage range, and using a power supply with a higher voltage than the LED's rated voltage can lead to excessive current flow, overheating, and ultimately, the failure of the LED.
