6-Pin Solderless IP67 RGB+CCT COB LED Strip Clip Connector (14mm) ~ UniColor Series

LED strip connector only ~ all other components are sold separately

Description

The UniColor IP67 COB series is an RGB+CCT 6-pin wire connector built for secure, weather resistant connections in COB tape light systems. It is designed specifically for UniColor IP67 COB tape and supports stable performance in outdoor and wet location lighting installations where durability and connection reliability are required.

This UniColor IP67 COB series enables tape to tape and tape to wire connections without soldering, helping speed up installation while maintaining electrical integrity. It ensures accurate RGB and CCT signal transfer across the lighting system and reduces the risk of loose or inconsistent connections in demanding environments.

Designed to match IP67 rated COB tape light products, this IP67 connector provides a clean, dependable fit and strong contact across all six pins. It is suitable for professional LED strip lighting projects that require a solder free RGB CCT connector solution with consistent output, secure locking, and long term outdoor usability.

General specifications

• Sold as single
• Connector type: 6 pin
• Tape width: 14mm (0.55″)
• Max power: 5.5A
• Compatible wire gauges: 22 AWG
• IP rating: IP67

Downloads

• Cut sheet

Important notes

• Items in stock are shipped the same day from Knoxville, Tennessee, United States.
• Bulk pricing is available on request.
