RGBW 4-Ch Constant Current LED Controller with DALI (350mA) ~ Model DLX1224-4CC350-DALI

Controller only ~ power supply, LEDs and all other accessories are sold separately

Description

DLX1224-4CC350-DALI LED controller is a high-efficiency device specially designed to power LEDs directly in constant current, delivering an output of 4x350mA. With support for both DMX512+RDM and DALI bus commands, it provides flexible control options, including RGB or RGBW color management.

The LED controller operates on a DC input of 12-24V DC and features local command functionality via dip switch settings. Key features include soft start/stop, optimized output curve, and an extended temperature range for enhanced performance. It boasts a typical efficiency of over 95% and is backed by a 5-year warranty, ensuring reliable operation and consistent brightness control, including the ability to adjust brightness down to complete off.

General Specifications

• Dimensions: 88 x 54 x 26mm (3.46” x 2.13” x 1.02)
• Model: DLX1224-4CC350-DALI
• Voltage Range: 12-24V DC
• Max Output Power: 4 x 350mA
• Output Channels: 4
• Control: RGB or RGBW Color
• Bus: DMX
• Working Temperature Range: -10/+40°C

Downloads

• DLX1224-4CC350-DALI cut sheet

Important Notes

• Items in stock are shipped the same day from Knoxville, Tennessee, United States
• Bulk pricing is available on request
