White High CRI IP20 LED Strip ~ Liatris Series For Sale

LED strip only ~ Profile, channel, covers, end caps and all other accessories are sold separately

White High CRI IP20 LED Strip (48V) ~ Liatris Series Wire4Signs LED Buy Per FT

Description

48 Volt LED Strip Lights White High CRI IP20 ~ Liatris Series

Our Liatris Series high CRI IP20 48V LED light strip offers a color rendering index of Ra80+ guaranteeing excellent lighting and consistent color rendering. But if you require longer runs of lights, this 48V lighting system is the solution. Additionally, 48 volt LED strip lights are less susceptible to voltage drop. Meaning you can also connect longer lines without needing additional power supplies.

General specifications

Chip: SMD 2835 (CRI80+)
Colors available: 2700K Ultra Warm White, 3000K Warm White, 4000K Natural White
LED strip width: 8mm
Dimmable: Yes
Supply voltage: 48V DC
LED density: 78 LEDs/m
Power consumption: 9.6 W/m
Luminous flux:
- 2700K: 1567 lm/m
- 3000K: 1600 lm/m
- 4000K: 1618 lm/m
Luminous efficiency: 166 lm/W
Cutting pitch: Every 166mm (6.53")
IP rating: IP20 non-waterproof
Beam angle: 120°
Mounting method: 3M double-sided tape

Downloads

Liatris cut sheet

Important notes

Items in stock are shipped the same day from Knoxville, Tennessee, United States.
Bulk pricing is available on request.

What makes us different from others?

High CRI LED Strip not made in China
Factory with over 20 years of experience in the lighting market
Carefully selected components from leading brands
Designed by engineers with many years of experience
All production batches go through a 5-step quality control
Our High CRI LED Strip rolls are also available in 5m (16.4ft) and contractor bulk LED strip 100m (328ft) rolls (on demand)
>5 year warranty

Need help selecting an LED driver that'll work for your project?

Use the LED driver selector tool

A table comparing the facets of 5 products
Facet	White High CRI IP20 LED Strip (24V) ~ White Iris Series View details	White High Output IP20 LED Strip (24V) ~ King Protea Series View details	White Ultra High Power IP20 LED Strip (24V) ~ Cardinal Flower Series View details	Single Color High Power IP20 LED Strip (24V) ~ Carnation Series View details	IP20 Indoor Ambient Lighting LED Strip (24V) ~ Decor Series View details
Product variants
Product variants	Color Cool white (6000K), Natural white (4000K), Warm white (3000K), Ultra warm white (2700K), Ultra warm white (2200K) LEDs/meter (wattage) 180 LEDs/m (12.8 W/m), 120 LEDs/m (8.4 W/m), 60 LEDs/m (4.8 W/m) Roll Length Per foot, 5m (16.4ft), 100m (328ft)	Color Warm white (3000K), Natural white (4000K), Cool white (6000K) LEDs/meter (wattage) 120LEDs/m (16.5W/m) Roll length 5m (16.4ft), Per foot, 100m (328ft)	Color Warm white (3000K), Natural white (4000K), Cool white (6000K) LEDs/meter (wattage) 224 LEDs/m (23W/m) Roll Length 3m (9.84ft)	Color Blue, Green, Red, Yellow LEDs/meter (wattage) 60LEDs/m 4.8W/m, 120LEDs/m 8.4W/m, 180LEDs/m 12.8W/m Roll Length Per foot, 5m, 100m	Color Ultra warm white 2700K, Warm white 3000K, Natural white 4000K, Cool white 6000K, Red, Green, Blue LEDs/meter (wattage) 60 LEDs/m (1.32W/m), 60 LEDs/m (2.6W/m) Roll Length 5m (16.4ft), Per foot, 100m (328ft)
Special features
Special features	Waterproof	Waterproof	Waterproof	Waterproof	-
