Compact IP67 Waterproof LED Driver (5V) ~ Meanwell LPV Series

LED power supply only ~ LED strip and all other components sold separately

Description

The Meanwell LPV series power supplies are compact waterproof (IP67) LED drivers for constant voltage (C/V) applications. These waterproof LED power supplies are ideal for outdoor applications such as signage lighting and decorative or festive lighting.

These LED drivers have a wide range AC input capability which means they can be installed on most power systems, and a selection of output voltages to match your LED strip or modules whether they are 5V pixel strips, or 12V or 24V LED strips.

General specifications

• Input voltage:
  • LPV 20-100: 90-264V AC (Class II 2-wire)
  • LPVL 150: 90-132V AC (Class II 2-wire)
• Connection type: Flying leads
• Electrical protections: Short-circuit, Overload, Over-voltage, Over temperature
• Surge protection: 3kV Input-Output
• Environmental protection: IP67 waterproof
• Working temperature: -22°F to 158°F (-30°C to 70°C)
• Certifications: IEC/EN 62368-1
• Warranty: 2 years

Downloads

• LPV20 (15-20W) cut sheet
• LPV60 (40-60W) cut sheet

Important notes

• Items in stock are shipped the same day from Knoxville, Tennessee, United States.
• Bulk pricing is available on request
