DMX 4-Ch Constant Current LED Controller (350mA) ~ Model DLX1224-4CC350-DMX
Product details
Controller only ~ power supply, LEDs and all other accessories are sold separately
Description
DLX1224-4CC350-DMX LED controller is a versatile 4-channel dimming solution designed for controlling multiple LED channels via the DMX512 protocol. With a DC input of 12-24V DC, it supports both DMX512+RDM and DALI bus commands, offering flexibility in LED strip control.
This LED controller manages RGB or RGBW color outputs with precision, providing constant current at 350mA. Featuring a soft start and stop function, it ensures smooth transitions in brightness, with the ability to dim LEDs to complete off. The optimized output curve enhances performance, and its efficiency exceeds 95%. Engineered to operate within an extended temperature range, the controller is fully tested for functionality and backed by a 5-year warranty.
General Specifications
- Dimensions: 88 x 54 x 26mm (3.46” x 2.13” x 1.02)
- Model: DLX1224-4CC350-DMX
- Voltage Range: 12-24V DC
- Max Output Power: 4 x 350mA
- Output Channels: 4
- Control: RGB or RGBW Color
- Bus: DMX
- Working Temperature Range: -10/+40°C
